MRCOOL® DIY® 5th Gen 2-Zone 18,000 BTU Ductless Mini Split Air Conditioner & Heat Pump with (16ft + 16ft) Pre-Charged Line Sets (6K+12K), DIYM218HP
MRCOOL® DIY® 5th Gen 2-Zone 18,000 BTU Ductless Mini Split Air Conditioner & Heat Pump with (16ft + 16ft) Pre-Charged Line Sets (6K+12K), DIYM218HP is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Care information
Care information
Care kits are available on our website! Grab yours now.
Delivery and Shipping
Delivery and Shipping
Delivery times may vary by location but our delivery shipping times are 3-7 days.
Specifications
Specifications
MRCOOL® DIY® 5th Gen 2-Zone 18,000 BTU Ductless Mini Split Air Cond...
Description
Description
Description DIYM218HPW02D00
Take control of your comfort with the MRCOOL® DIY® 5th Gen Multi-Zone Mini Split System - the easiest and most affordable way to get powerful, energy-saving heating and cooling without hiring a pro.
- Two Rooms, Perfect Comfort: Heat or cool two spaces that are 200 sq. ft. and 550 sq. ft. each with independent temperature control for personalized comfort.
- Truly DIY-Friendly: Forget expensive installs - no HVAC license or special tools required. If you can use basic hand tools, you can do this.
- No Hassle Setup: Comes with 2x 16ft pre-charged DIY® Quick Connect® line sets, so there’s no messy refrigerant handling or vacuuming. Just connect and enjoy.
- Year-Round Savings: Boasting up to 23.9 SEER2 cooling efficiency and 10 HSPF2-4 heating performance, this system delivers serious energy savings.
- Built for Every Season: Stay cozy even in the dead of winter - reliable heating works all the way down to -13°F. 100% at 5 degrees
- Strong Warranty Protection: Includes 7-Year Compressor Replacement and 5-Year Parts Coverage.
Whether it’s hot summer days or freezing winter nights, the MRCOOL® DIY® Mini Split keeps your home comfortable and your energy bills low. Smart. Simple. Affordable.
SPECIFICATIONS & DIMENSIONS
SYSTEM OVERVIEW
| System Type | Ductless Mini Split Air Conditioner & Heat Pump |
|---|---|
| Zones | 2 |
| Capacity | Total: 18,000 BTU Zone 1: 6,000 BTU Zone 2: 12,000 BTU |
| Coverage Area | Total: 650 sq. ft. Zone 1: 200 sq. ft. Zone 2: 550 sq. ft. |
| Refrigerant | R-454B |
| Line Sets Included | 2 x 16ft Pre-Charged Line Sets |
| Warranty | 7 Years Compressor 5 Years Parts |
| INDOOR UNIT (6K) x 1 | |
|---|---|
| Model | DIY-06-HP-WMAH-230D25-O |
| Dimensions | 31.57" W x 7.44" D x 11.69" H |
| Mounting Type | Wall |
| Cooling Capacity | 6,000 BTU |
| Heating Capacity | 6,000 BTU |
| Coverage Area | 100 to 200 sq. ft. |
| Liquid Line Size | 1/4" |
| Suction Line Size | 3/8" |
| Modes | Auto Mode: Automatically selects heating or cooling based on the room's temperature. Cool Mode: Lowers the room temperature to your desired setting. Heat Mode: Raises the room temperature to your desired setting. Fan-Only Mode: Circulates air without heating or cooling. Dry Mode (Dehumidification): Reduces humidity levels in the room. Sleep Mode: Gradually adjusts temperature settings for comfortable sleep and energy savings. |
| Weight | 24.47 lbs |
| INDOOR UNIT (12K) x 1 | |
|---|---|
| Model | DIY-12-HP-WMAH-230D25-O |
| Dimensions | 31.57" W x 7.44" D x 11.69" H |
| Mounting Type | Wall |
| Cooling Capacity | 12,000 BTU |
| Heating Capacity | 12,000 BTU |
| Coverage Area | 351 to 550 sq. ft. |
| Liquid Line Size | 1/4" |
| Suction Line Size | 3/8" |
| Modes | Auto Mode: Automatically selects heating or cooling based on the room's temperature. Cool Mode: Lowers the room temperature to your desired setting. Heat Mode: Raises the room temperature to your desired setting. Fan-Only Mode: Circulates air without heating or cooling. Dry Mode (Dehumidification): Reduces humidity levels in the room. Sleep Mode: Gradually adjusts temperature settings for comfortable sleep and energy savings. |
| Weight | 24.47 lbs |
| OUTDOOR UNIT (18K) x 1 | |
|---|---|
| Model | DIY-MULTI3-18HP230D-O |
| Dimensions | 35.04" W x 13.46" D x 26.50" H |
| Cooling Capacity | 18,000 BTU |
| SEER2 | 23.9 |
| EER2 | 13.0 |
| Heating Capacity | 18,000 BTU |
| HSPF2-4 | 10.0 |
| HSPF2-5 | 7.8 |
| Outdoor Noise Level | 60.0 dB(A) |
| Outdoor Operating Temperature | Cooling: -13°F – 122°F Heating: -13°F – 75°F |
| Voltage | 208–230V |
| Phase | 1 |
| Cycle | 60Hz |
| Min Circuit Ampacity | 16.0A |
| Max Fuse Breaker | 20.0A |
| Weight | 101.63 lbs |
| Certifications | ENERGY STAR Certified AHRI Certified UL Listed ETL Listed |
