MRCOOL Olympus 18,000 Btu 1.5 Ton Ducted Mini Split Air Handler 230V/60Hz, DUCT-18HP-230B-O
MRCOOL Olympus 18,000 Btu 1.5 Ton Ducted Mini Split Air Handler 230V/60Hz, DUCT-18HP-230B-O
Available in stock (68)
Description
(NON-DIY)
The MRCOOL® OLYMPUS 18K DUCT Air Handler is a compact and efficient heating and cooling solution designed for spaces up to 750 square feet. Its ceiling-integrated design ensures a seamless, modern look that fits effortlessly into both residential and light commercial spaces. With easy-to-use controls, eco-friendly refrigerant, and dependable performance, this unit offers a perfect balance of comfort, style, and sustainability.
- Discreet Design: Ceiling-integrated setup allows for a flush, modern installation that complements any interior space.
- Ideal Coverage: Designed to efficiently heat and cool rooms up to 750 sq. ft., making it perfect for bedrooms, offices, or small living areas.
- Convenient Controls: Includes both a wired wall-mounted controller and a handheld remote for flexible, easy operation.
- Eco-Friendly Refrigerant: Utilizes R-454B refrigerant with low global warming potential, combining environmental responsibility with strong performance.
- Quiet Operation: Engineered for minimal noise, maintaining a peaceful atmosphere while delivering consistent comfort.
- Reliable Warranty: Protected by a 5-year parts warranty for long-term peace of mind.
Professional Installation Required
As part of the Olympus professional series, this air handler must be installed by a licensed HVAC technician. Pre-charging, evacuation and pressure testing ensures the system’s refrigerant integrity, energy efficiency and warranty eligibility.
SPECIFICATIONS & DIMENSIONS
| DIMENSIONS | |
|---|---|
| Dimensions | 34.65" W x 26.54" D x 8.27" H |
| Mount Type | Ducted |
| Weight | 54.45 lbs |
| CAPACITY & PERFORMANCE | |
| Tonnage | 1.5 Ton |
| Capacity | 18,000 BTU |
| Coverage Area | 501 to 750 sq ft. |
| ELECTRICAL REQUIREMENTS | |
| Voltage | 208-230V |
| Phase | 1 |
| Cycle | 60 Hz |
| Max Fuse Breaker | 15A |
| Min Circuit Ampacity | 3A |
| REFRIGERANT & PIPING | |
| Refrigerant Type | R-454B |
| Liquid Line Size | 1/4" |
| Suction Line Size | 1/2" |
| FEATURES | |
| Fan Only Option | Yes |
| Quiet Mode | Yes |
| Auto Cool | Yes |
| Wifi Compatibility | No |
| App Compatibility | No |
| Works with IOS | No |
| Works with Android | No |
| Remote Control Included | Yes |
| CERTIFICATION & WARRANTY | |
| Certifications | UL Listed, ETL Listed, CSA Listed |
| Warranty | 5 Year Parts |
Why the Olympus Series is the Best Choice
Within the “Good, Better, Best” lineup of MRCOOL® offerings, the Olympus Series is the Best. It’s designed for professional installations, larger zones, full comfort systems, and offers the highest tier of durability and performance. Ideal for homeowners and contractors seeking premium ducted mini-split solutions that deliver reliable long-term comfort.
- Premium build for demanding comfort applications
- Compatible with Olympus outdoor condensers for single- or multi-zone setups
- Engineered for quiet, efficient performance
- Full nationwide shipping from the USA’s most trusted MRCOOL® dealer
