MRCOOL® VersaPro® 3-Ton Package Heat Pump 13.4 SEER2 (34,200 BTU Cooling & Heating) R-454B — MPH361HO13C

Product Description

The MRCOOL® VersaPro® MPH361HO13C Package Heat Pump is a 3-ton, all-in-one HVAC system designed to deliver dependable, energy-efficient comfort in a single compact outdoor unit. Built for homeowners upgrading older systems or replacing split equipment, this packaged heat pump simplifies installation while providing powerful heating and cooling performance year-round.

Rated at 13.4 SEER2, the VersaPro® 36K efficiently cools during peak summer heat while delivering strong heating output down to -0.4°F, making it a reliable solution for a wide range of climates. The system operates on R-454B refrigerant, a next-generation, low-GWP alternative that meets modern environmental standards without sacrificing performance.

Durability is engineered into every detail. The power-painted galvanized steel cabinet protects internal components from corrosion, moisture, and harsh outdoor conditions. A horizontal discharge design reduces operational noise—an important advantage for residential neighborhoods and tight installation spaces. Inside the cabinet, aluminum tubing and fin coils enhance heat transfer efficiency while offering superior corrosion resistance compared to copper coils.

At the core of the system, a high-efficiency scroll compressor, paired with ECM motors for both the condenser fan and blower, delivers smooth airflow, precise temperature control, and reduced energy consumption. Integrated safety controls actively monitor system pressures and coil temperatures, helping ensure consistent, reliable operation even under demanding conditions.

Backed by industry-leading warranties, including 10-year parts and 10-year compressor coverage with registration, the MRCOOL® VersaPro® MPH361HO13C is a long-term investment in comfort, efficiency, and peace of mind.



KEY FEATURES & BENEFITS

• 3-Ton Packaged Heat Pump – Heating & cooling in one outdoor unit
• 13.4 SEER2 Efficiency – Lower operating costs & improved energy savings
• R-454B Refrigerant – Low-GWP, future-ready refrigerant
• 34,200 BTU Cooling & Heating – Balanced year-round comfort
• Horizontal Discharge Design – Quieter residential operation
• All-in-One Package Unit – No indoor air handler required
• Galvanized Steel Cabinet – Weather-resistant and corrosion-protected
• Aluminum Coil Technology – Enhanced heat transfer & longevity
• Auxiliary Heat Ready – Supports 5kW, 7.5kW, 10kW, or 15kW heat kits
• AHRI, UL, ETL, CSA Certified – Verified safety & performance



ELECTRICAL & PERFORMANCE

• Voltage: 208 / 230V
• Phase: 1
• Frequency: 60 Hz
• Max Breaker: 35 Amps
• Minimum Circuit Ampacity (MCA): 27.1 Amps
• CFM: 1200
• Min Ambient Cooling: 32°F
• Min Ambient Heating: -0.4°F

TECHNICAL SPECIFICATIONS

• Tonnage: 3 Ton
• SEER2: 13.4
• EER2: 11.2
• HSPF2-4: 6.7
• Cooling Capacity: 34,200 BTU
• Heating Capacity: 34,200 BTU
• Refrigerant: R-454B (60 oz)
• Compressor Type: Scroll
• Blower Motor: ECM (3-Speed)
• Condenser Fan Motor: ECM
• Control Type: 24V Thermostat
• Aux Heat Available: Yes



• 5kW         Model- MHK05PB
• 7.5kW      Moldel- MHK07PB
• 10kW       Model- MHK10PB
• 15kW       Model- MHK15PB



DIMENSIONS & WEIGHT

Unit Dimensions

• Width: 37.75 in
• Height: 24.81 in
• Depth: 52 in

Weight

• Net Weight: 337 lbs
• Shipping Weight: 351 lbs

WARRANTY INFORMATION

• Registered Warranty

• 10-Year Parts
• 10-Year Compressor
• Base Warranty

• 5-Year Parts
• 5-Year Compressor



FREQUENTLY ASKED QUESTIONS

Q: Is this a complete HVAC system?

A: Yes. This is a self-contained packaged heat pump, requiring no separate indoor air handler.



Q: Does this unit work in colder temperatures?

A: Yes. Heating operation is supported down to -0.4°F, with optional auxiliary heat kits available.



Q: What refrigerant does this system use?

A: R-454B, a low-GWP refrigerant compliant with modern efficiency standards.



Q: Can electric backup heat be added?

A: Yes. Compatible with 5kW, 7.5kW, 10kW, and 15kW auxiliary heat kits.



Q: Is professional installation recommended?

A: Yes. Installation should follow local electrical and mechanical codes.
