MRCOOL® 36k 5th Gen DIY® Multi-Zone Bundle with 9K + 18K Air Handlers & 16ft Line Sets (230V) — DIYM236HPW02D00

Product Description

Model: DIYM236HPW02D00

MRCOOL DIYM236HPW02D00 – 36k 5th Gen DIY Multi-Zone Bundle with 9K + 18K & 16ft Line Sets

The MRCOOL DIYM236HPW02D00 bundle is a 5th Generation multi-zone DIY system built around the DIY-MULTI5-36HP230D-O 36,000 BTU condenser, paired with a 9,000 BTU wall-mount air handler, an 18,000 BTU wall-mount air handler, and two 16-foot R-454B Quick-Connect® line sets. It’s a perfect configuration for homeowners who want true DIY installation, quiet comfort, and room-by-room control without paying HVAC labor rates.

Use the 9K indoor unit for a bedroom, office, or flex room up to about 400 sq. ft., and the 18K indoor unit to handle a medium-to-large space up to about 800 sq. ft. The 36k multi-zone condenser can support up to 5 total zones, so you can always add more indoor units later as your needs grow.

Because every major refrigerant connection is handled by pre-charged R-454B Quick-Connect® line sets, installation is vacuum-free and gauge-free—exactly what serious DIYers want.



What’s Included in the MRCOOL DIYM236HPW02D00 Bundle

✔ 1 × 36,000 BTU 5-Zone DIY Condenser –

DIY-MULTI5-36HP230D-O

• 36,000 BTU 5th Gen DIY® multi-zone condenser, 208/230V
• Supports up to 5 indoor zones from a single outdoor unit
• Up to 23 SEER2, 9.9 HSPF2-4 for high efficiency
• Factory-charged with R-454B, a more efficient, lower-GWP refrigerant
• Designed specifically for MRCOOL 5th Gen DIY air handlers
• Uses DIY Quick-Connect® ports—no vacuum pump, no refrigerant handling
• SmartHVAC® App control plus Amazon Alexa & Google Assistant integration
• Quiet rotary inverter compressor with DC inverter technology
• Gold Fin® corrosion-resistant coating for long outdoor life
• Ideal system capacity for homes up to ~1,500 sq. ft., depending on layout

✔ 1 × 9,000 BTU DIY Wall-Mount Air Handler –

DIY-09-HP-WMAH-230D25-O

• 9,000 BTU wall-mount indoor unit, 208/230V
• Comfort coverage for rooms up to 400 sq. ft.
• Perfect for bedrooms, home offices, nurseries, and bonus rooms
• Works with 1/4” × 3/8” R-454B line sets
• Very quiet operation with multiple fan speeds and Quiet Mode
• Follow Me® function uses the remote’s sensor for more accurate temperature at your location
• Dry Mode helps remove excess humidity
• Built-in WiFi with SmartHVAC® App, plus Alexa & Google Assistant compatibility
• Includes DIYPRO® cable, so you don’t need electrical conduit

✔ 1 × 18,000 BTU DIY Wall-Mount Air Handler –

DIY-18-HP-WMAH-230D25-O

• 18,000 BTU wall-mount indoor unit, 208/230V
• Ideal for mid-to-large spaces up to 800 sq. ft.
• Great for living rooms, large bedrooms, big rec rooms, or basements
• 1.5 ton capacity with high efficiency and ENERGY STAR® performance
• Pairs with 1/4” × 1/2” R-454B Quick-Connect line sets
• Ultra-quiet with five fan speeds and advanced airflow control
• Dry Mode and Follow Me® remote for comfort and humidity control
• WiFi built in—control from the app, Alexa, or Google Assistant
• Includes DIYPRO® cable for easier, cleaner electrical installation

✔ 1 × 16ft R-454B Line Set (1/4” × 3/8”) –

DIY16-1438-O

• 16-foot pre-charged R-454B Quick-Connect® line set
• Sized for 6K, 9K, and 12K MRCOOL DIY indoor units
• 1/4” liquid line × 3/8” suction line
• Fully sealed, pre-charged, vacuum-free design
• Quick-Connect® fittings designed to pair with DIY condenser and air handler

✔ 1 × 16ft R-454B Line Set (1/4” × 1/2”) –

DIY16-1412-O

• 16-foot pre-charged R-454B Quick-Connect® line set
• Sized for 9K, 12K, and 18K MRCOOL DIY indoor units
• 1/4” liquid line × 1/2” suction line
• Pre-charged, vacuum-free, and ready for DIY installation
• Quick-Connect® threaded fittings—no brazing, flaring, or nitrogen purge required



Why Homeowners Choose This 9K + 18K, 36k Multi-Zone Bundle

This configuration is extremely popular because it targets exactly how people use their homes:

• 9K zone: bedroom, office, nursery, or guest room up to 400 sq. ft.
• 18K zone: living room, den, big bedroom, small apartment, basement up to 800 sq. ft.



You get two truly useful zones from day one, plus extra capacity on the condenser to add up to three more indoor units later if needed. It’s perfect for:

• Upgrading from window units or electric baseboards
• Zoned comfort in an older home with no ducts
• Garage apartments, in-law suites, and ADUs
• Investors and flippers who want modern HVAC without running ductwork



Key Benefits of the DIYM236HPW02D00 System

• True DIY install – No vacuum pump, no gauges, no EPA certification
• Future-ready refrigerant – Uses R-454B instead of R-410A
• High efficiency – Up to 23 SEER2 and strong HSPF2 performance
• Zoned comfort – Independently control your 9K and 18K spaces
• Smart control built-in – App, WiFi, Alexa, and Google voice
• Quiet operation – Whisper-quiet indoor sound levels ideal for bedrooms
• Expandable multi-zone – Start with 2 zones; grow to 5 zones over time
• Strong warranties – Up to Limited Lifetime Replacement when registered with MRCOOL® Care, plus 5-Year Parts and 7-Year Compressor base warranties



Ideal Applications

• Primary living area + main bedroom
• Basement + upstairs office
• Small rental or ADU with two critical comfort zones
• Homes without ductwork wanting a clean, efficient upgrade



If you want serious multi-zone comfort with DIY-ready hardware and smart controls, the MRCOOL DIYM236HPW02D00 is one of the most flexible and future-proof setups you can install yourself.
